Person detection
Detect walking or running targets approaching, crossing or moving along a protected perimeter.
24 GHZ PERIMETER SECURITY RADAR
MSR-S200 200 m Perimeter Security Radar
Detect and track people around prisons and other critical sites. MSR-S200 provides target position, speed and continuous track data for security platforms and camera-linked alarm systems.
IP67 enclosureEthernet · TCP100 ms data update
MSR-S200PERIMETER DETECTION
Radar data for high-security sites
MSR-S200 monitors a defined outdoor corridor without depending on visible light. It keeps separate tracks for multiple moving people and supplies target data to the security system for visualization, alarm logic and camera coordination.
Multi-target tracking
Maintain independent tracks for up to 32 targets, including position, speed and movement history.
All-weather monitoring
Operate continuously through darkness, rain and snow without relying on scene illumination.
Security-system integration
Send target data over Ethernet for map display, alarm rules, recording and camera cueing.
TARGET DATA & INTEGRATION
Know where the target is and how it is moving
MSR-S200 reports tracked-target information through Ethernet using TCP. Your security platform can use the target position and speed to display movement, maintain a trajectory, trigger zone rules and direct a camera toward the event. For the detailed communication protocol and integration documentation, please contact our technical team.
SENSINGMSR-S200 radarDetect and track moving people
→
ETHERNETTarget dataID · position · speed · track
→
SECURITY SYSTEMAlarm + cameraVisualize · verify · record · respond
PRIMARY APPLICATIONS
Built for prisons and critical perimeters
Prison perimeter securityTrack people near walls, restricted corridors and escape-risk areas.
Military and border sitesMonitor exposed outdoor approaches where continuous long-range awareness is required.
Airports, ports and oil depotsProtect sensitive infrastructure and cue surveillance cameras toward moving targets.
Industrial and storage compoundsAdd radar tracking to high-value facilities that require stronger detection than video alone.
System note: Radar supplies target tracks; the security platform defines alarm zones and coordinates cameras, recording and response workflows.
Explore the perimeter security solution →PRODUCT & COVERAGE
Compact IP67 radar for outdoor mounting
The MSR-S200 enclosure is designed for permanent perimeter installation. Final coverage depends on mounting position, site geometry, target path and the clear field of view.
TECHNICAL SPECIFICATIONS
MSR-S200 performance
Use these published values for initial system design. Detection performance must be validated against target movement, installation angle, obstructions and the actual perimeter environment.
Confirm project fit| Parameter | Specification |
|---|---|
| Frequency | 24 GHz |
| Bandwidth | 150 MHz |
| Maximum transmitting power (EIRP) | 26 dBm |
| Detection distance | 1–200 m |
| Maximum lateral coverage | 140 m |
| Distance accuracy | ±0.25 m or ±2.5% |
| Radial speed range | -14 to +14 m/s |
| Speed accuracy | ±0.25 m/s |
| Tracked targets | Up to 32 |
| Horizontal / vertical 3 dB angle | 24° / 14° |
| Data update time | 100 ms |
| Communication | Ethernet · TCP |
| Supply voltage / power | 8–24 V DC · ≤6 W |
| Operating temperature | -40 to +85°C |
| Protection rating | IP67 |
| Dimensions / weight | 147 × 119 × 40 mm · 510 g |
SITE PLANNING
Start with the protected corridor
Share a plan or photograph of the perimeter, target path, mounting position and camera locations. We can help evaluate the required radar orientation and integration approach.
Avoid walls, dense vegetation and large metal objects blocking the radar field of view.
Position the radar so the expected walking or running path remains inside the monitored sector.
Connect radar target data to the security management, alarm or camera-control platform.
Plan outdoor cabling, surge protection and waterproof connections for the installation.
PROJECT SUPPORT
Validate the perimeter before deployment
Send the wall or fence layout, corridor width, required range, mounting position, network environment and expected alarm workflow. Our team can help confirm whether MSR-S200 fits the site.
01Site geometry02Target paths03TCP integration04Field validation
TECHNICAL FAQ
Common MSR-S200 questions
What data can the MSR-S200 provide?
The radar provides tracked-target information including target identity, position, speed and movement data. A connected platform can visualize tracks, maintain trajectories and apply alarm-zone logic.
How many targets can one radar track?
MSR-S200 can track up to 32 targets simultaneously under suitable field conditions.
Does it work at night and in bad weather?
Yes. Radar sensing does not depend on ambient light and is designed for 24-hour outdoor operation through darkness, rain and snow.
Can it control a PTZ camera?
The radar supplies target position and movement information. Your integrated security platform can use that data to cue a compatible camera and verify the alarm visually.
How does the radar connect to the security system?
MSR-S200 uses Ethernet communication with TCP. For the detailed communication protocol, please contact our technical team and describe your platform.
What information should I send before ordering?
Provide the perimeter layout, corridor width, mounting position, expected target paths, camera arrangement, network environment and required alarm workflow.
DISCUSS AN MSR-S200 PROJECT
Send us your perimeter layout.
We will use your protected corridor, mounting conditions, camera arrangement and Ethernet integration requirements to recommend the next technical step.
